Digital VT100 Terminal

by billdeg - 09/12/2015
Total messages in this thread: 1
Digital VT100 Terminal
The DEC VT100 is probably the most famous terminal of the late 70's early 1980's. This unit has the Advanced Video Option (AVO) installed which allows 24 lines of text in 132 column mode. Click for larger view.
Being that I will use this terminal mostly for accessing my VAX 4000, I set it to default to 19200 baud. The other "Setup B" settings are: 1) 0101 2) 0011 3) 0010 4) 1010 So, if you read this post and you are struggling with getting your VT100 to communicate with your computer... First connect your computer to the terminal. You may need a NULL MODEM adapter (I did not), situations vary. Understand the communications settings your computer or server requires. Make sure your vt100 is in ONLI... [ read more ]

TRW 530 Information Processing System

by billdeg - 09/09/2015
Total messages in this thread: 1
Cover of the TRW 530 Information Processing System Operator's Manual. Click to access directory.
This is a rare scan, not found elsewhere so I posted here.
The front panel of the TRW 530. Click for larger view.
... [ read more ]

New ETKM 8800b Turnkey Monitor Found

by billdeg - 04/25/2015
Total messages in this thread: 2
Last Post: [ ETKM = Vector Graphics Monitor ] 08/23/2015
A few ROMs for the 8800 I have collected including a totally new to me "ETKM" Turnkey Monitor Program that is HEX, not octal based. I still need to take a look at it in a HEX editor so I can see what commands are available and learn more about what it does. So far I learned it has an E command as in E 0000 - 0FFF (show me a dump of RAM from this range). Stay tuned.... [ read more ]

TRS 80 Model III Hi-res Graphics Board

by billdeg - 09/05/2014
Total messages in this thread: 4
Last Post: [ Compatibility Issues ] 08/19/2015
TRS 80 Model III 26-1125 hi-res board demo image
TRS 80 Model III 26-1125 hi-res board demo image. Click on image for larger view.
Here are the initialization commands necessary for a model III with programs written with micro-labs GBASIC, and a model III 26-1125 graphics board: A=PEEK(16912) OR 16 POKE 16912, A OUT 236,A TRS 80 Model III 26-1125 hi-res board
TRS 80 Model III 26-1125 hi-res board. Note that to get to the board I had to first remove the factory-in... [ read more ]

MITS 8800b Turnmon 9600 baud

by billdeg - 09/15/2013
Total messages in this thread: 6
Last Post: [ Load BASIC into ROMS ] 08/09/2015
Pertec MITS altair 8800b Turnkey model key view.
A view of the on/off key on the Pertec / MITS 8800b Turnkey model. The system required some minor repairs, a short was detected in the turnmon board preventing I/O from the Turnmon board. I repaired some burned out traces and set the baud rate to 9600.
Pertec / MITS Altair 8800b Turnkey model 9600 baud jumpers
View of a repaired turnkey "turnmon" board. Note S0, S1, and S2 are jumpered to produce 9600 baud. S0 required minor repair, some of the original trace metal was lost. The staining is only cosmetic. Click image for larger vie... [ read more ]

Friden Model 132 Electronic Calculator

by billdeg - 12/17/2009
Total messages in this thread: 3
Last Post: [ repair complete ] 07/27/2015
The 1965 Friden 132 Electronic Calculator was the first electronic calculator capable of doing square root.
The 4 row display of the Friden 132.
More pictures ... [ read more ]

PDP 11/40 Power Supply Issue!

by billdeg - 08/12/2008
Total messages in this thread: 14
Last Post: [ Basic stress testing ] 07/17/2015
Nooo! The console and power supply light flicked out while in use. WTD: Power Supply or Power Supply Module. The part number on the front is "H742a" and it's the big part of the power supply in the back. In front (looking from the side) are power modules. The modules and the console power are attached to the "H742a" Other H74x supplies should work. Here is the wording on the unit: Dec Power Supply H742a Caution AC & DC OUTPUTS ARE PRESENT WHEN LIGHT IS ON POWER ON (( )) ------------ where (( )) = the light bulb. The supply's red indicator light no longer comes on, nor do the console lights, though the fans still run. In the meantime I will test with a volt meter and so on, maybe there's a bad connection. More to follow.... [ read more ]

1972 DEC idacs 11/07 Industrial PDP 11

by billdeg - 07/14/2015
Total messages in this thread: 1
Digital Equipment Corporation idacs 11/07 industrial PDP 11 computer
The circa 1972 Digital Equipment Corporation idacs 11/07 industrial PDP 11 computer. Click for larger view.
Download Sales Brochure... [ read more ]

Xerox 820-II - Set Up

by billdeg - 01/06/2011
Total messages in this thread: 4
Last Post: [ Blew a Power Cap! ] 06/23/2015
The Xerox 820-II Computer with DD 8" and "Rigid" disk option.
Xerox is one of those computer companies, like Apple, whose computers you'd buy partially because of the brand name. At least that was the the case in early 80's. The initial reaction of consumers when the Xerox 820 series was announced was "Ah ha, watch out IBM, Xerox is getting in the game and they'll show everyone how to make a real computer". It did not quite work out that way, the 820 series was pretty boring - no mouse and no hi-res graphics like the Lisa-inspiring Xerox Star, the production version of the Xerox Alto. Instead, the 820-II was a business machine, and as such it wa... [ read more ]

1996 Digital AlphaServer 2100 4/275

by billdeg - 05/11/2015
Total messages in this thread: 8
Last Post: [ FTP Setup ] 06/20/2015
Digital AlphaServer 2100 4/275
The Digital Equipment Corp AlphaServer 2100 series model 4/275. This AlphaServer is powered by an Alpha 21064A microprocessor. Features include a 275-MHz CPU with 4 Mbyte cache; Click image for larger view.
So far the system powers up, initializes and then fails to load an operating system. This machine would have been shipped with OpenVMS, Digital UNIX or Windows NT. Click image to see larger view.
M... [ read more ]

DECpc 433SLC Laptop

by billdeg - 06/16/2015
Total messages in this thread: 1
Digital DECpc 433SLC laptop
The 33Mhz i486 Digital "DECpc 433SLC Premium" laptop model PCP38 - One of the last Digital-branded laptops made before the company was bought by Compaq. The SLC was first made available in February 1994 and would have been designed for Windows 3.11, but would have run Windows 95 as well.
More photos... [ read more ]

1993 Compaq Deskpro 5/60M

by billdeg - 06/16/2015
Total messages in this thread: 2
Last Post: [ Restoration progress ] 06/17/2015
1993 Compaq Deskpro 5/60M Pentium Computer
The unassuming Compaq Deskpro 5/60M computer is considered one of the first commercially-sold desktop computers with an Intel Pentium processor. Click for larger view.
EISA qVGA card
Pictured is a rare Compaq QVGA EISA video card. These were at the time Cadillac VGA cards, a good match for the system. The QVision VGA cards also appeared in AlphaServers. Click for larger view.
[ read more ]

Raspberry Pi as Gateway to Internet

by billdeg - 01/03/2015
Total messages in this thread: 3
Last Post: [ IRSSI IRC slashnet.net #vc ] 06/13/2015
Raspberry Pi as Internet Gateway for Vintage Computers
The Raspberry Pi can be used to connect vintage computers to the internet. This image shows my preference - A USB wireless dongle and a USB to serial cable. One could also use the serial port of the Pi, but that method is not covered here. The operating system I chose is a version of Debian Linux tailored for Apple II use (search the web for "IvanX" to download a copy with directions), but this Pi distro is also good for most other terminal software-driven vintage computers. Click for larger view.
The first thing I attempted was to connect a Digital VT102 terminal to the Raspberry Pi. I used a cabled ethernet conection rather than wireless. I also... [ read more ]

Items Wanted

by billdeg - 06/11/2015
Total messages in this thread: 1
This list is maintained regularly. Thread date is last update. Contact me Here. -"Regular" Vintage Stuff- PCS Micropac 80, Superpac 180 and related DATAC 1000 6502 trainer RCA COSMAC Microkit manual MPM-103. GO Tablet Model G400 power supply or battery (24V ). Commodore B Series hi-profile keyboard(s) NEC PC6011A Expansion Unit Computer Data Systems "Versatile 2" s-100 computer 1977 (Newark, Delaware USA computer) Casio FX-9000P Canon CX-1 or BX-3 Acorn BBC Model A Eagle Computer Eagle II E (I have disks, need computer) Sord SM80X Oki 1F COM7 laptop Morrow Decision 1 Microvoice Nugen Sycor Model 302 Key-Cassette Terminal California Technology International 1108-A Manual/documentation Any mid 70's micros like the Sphere, Compucolor II, HAL, Jupiter Computers Commodore 264 CBM VC 1020 or VIC... [ read more ]

The Digital Ultimate Workstation 533au2

by billdeg - 05/11/2015
Total messages in this thread: 2
Last Post: [ Resetting SYSTEM password Alpha 1200 ] 05/11/2015
The Digital Ultimate Workstation 533au2
The 1998 Digital Ultimate Workstation 533au2 was one of the last Digital-branded mini computers. Click image for larger view.
These machines shipped with either Windows NT® Server 4.0 or DIGITAL UNIX, but many installed OpenVMS as well. As you can see, this machine has OpenVMS 7.3 installed (the latest VMS release version as of this writing). Click for larger view.
Marketing Brochure: http://manx.c...ons/antonio/dec/EC-F869... [ read more ]
