TRS 80 Model 4P 26-1080 and 26-1080A

SHARE

Return to Threads

  TRS 80 Model 4P 26-1080 and 26-1080A by Bill Degnan - 11/25/2010 12:41
4 TRS 80 Model 4P computers.


Two of these are 26-1080's and Two are 26-1080A's. The green screen displays are 1080A's. Although some 1080's are non-gate array units, the 1080A's are probably all gate array.

To run the diagnostic package in the
ROM, hold down the period key ( . ) and then power on the system. You'll access a ROM program for testing the system. It looks like RAM tests.


Here is a picture of the two types of cover latches one can find on the 4P to clamp the cover to the chassis. I prefer the metal.


Notes from
4p Technical Reference Manual
http://www.classiccmp.or...nfield/trs80/m4tech.pdf

vTwo configurations of Random Access Memory (RAM) are
available on the Model 4P: 64K and 128K. The 64K and 128K
option use the 6665-type 64K x 1 200NS Dynamic RAM, which
requires only a single + 5v supply voltage.

-------------------

The Initialization section of the 4P Boot ROM performs these
functions:
1. Disables maskable and non-maskable interrupts

2 Interrupt mode 1 is selected

3 Programs the CRT Controller

4 Initializes the boot ROM control areas in RAM

5 Sets up a stack pointer

6 Issues a Force Interrupt to the Floppy Disk Controller
to abort any current activity

7 Sets the system clock to 4mhz

8 Sets the screen to 64 x 16
9 Disables reverse video and the alternate character
sets
10. Tests for . key being pressed*

11. Clears all 2K of video memory

* This is a special test If the . is being pressed then
control is transferred to the diagnostic RAM Test package in the
ROM All other keys are scanned via the Keyboard
Scanner

----------------------

When any key in the Function Group is pressed, it is recorded in RAM and will be used by the Control routine in directing the action of the boot. If more than one of these keys are pressed
during the keyboard scan, the last one detected will be the one that is used. The Function group keys are currently defined as:
F1 or 1 Will cause hard disk boot
F2 or 2Will c ause floppy disk boot
F3 or 3 Will force Model III mode

Left-Shift:Reserved for future use

Right-Shift:Boot from RS-232 port

Ctrl:Reserved for future use

Caps:Reserved for future use

L: Instructs the Control routine to
load the Model III ROM-image,
even if it is already loaded This
is useful if the ROM-image has
been corrupted or when switching
ROM-images. (Note that
this will not cause the ROMimage
to be loaded if the boot
sector check indicates that the
Model III ROM image is not
needed. Press " F3 or " F3 "
and " L " to accomplish that.
-----------------------


Reply
  Opening TRS 80 Model 4P by Bill Degnan - 11/27/2010 13:06
1. Remove 4 side cover screws
2. Remove handle in the back
3. Remove plastic cover
4. Unhook serial port connector from motherboard
5. Remove screws all along the bottom.
6. You should now be able to pry the bottom metal cover and expose the motherboard enough to remove the three power connectors and ground clamp from the motherboard, located opposite from the serial connector.

Reply
  26-1080A S/N 006296 by Bill Degnan - 11/27/2010 22:51

The 26-1080A with S/N 006296This is the report from the Ram Test diagnostic. 26-1080A S/N 006296



Boot Tests:
Pressing 1 causes the system to check for a hard drive, there is none system halts - OK
Pressing 2 causes the system to check for disk drive - hangs (see below)
Pressing 3 does nothing, there is no Model III ROM present. - OK

DISK BOOT / DEFAULT BOOT
System reports "Loading ROM Image" while the drive spins and shows a steady light but does not move the heads. After a few seconds, the head moves for a split second, the light goes out and the screen goes blank.

Reset - drive spins/lights for 5 seconds and then goes out.

Took unit apart, removed chips and re-seated them. Some were loose. Overall condition of motherboard was good, some spots cleaned.

Tested RAM in RAMCHECK unit, all were OK per the machine.

Re-ran RAM Test after re-assembling system/re-seating chips. No errors were detected after 30 minutes.

May be a bad disk drive.

Took pictures of the motherboard, re-seated chips, and tested RAM using RAMCheck unit

RAM OK.

Motherboard basically ok. Cleaned the crud off the board near U84, removed a little insect pod from the surface.

NEXT: Swap drives with known working.

Reply
  26-1080 S/N 002615 by Bill Degnan - 11/28/2010 22:47
26-1080 S/N 002615 has a bad 1 (right-hand) drive.


Drive 0 works. The only problem with this unit is that the keyboard has some marker ink to be removed, and drive 1 will not format disks. It reads disks fine. All other tests OK.

NEXT: Swap drives with 26-1080A 006296. Attempt to learn whether drive 1 of 006296 works. Swap drive 0 of 002615 with 006296 to see if drive 0 of 2615 works.
